Prescriptive Guidance
See real-time, turn-by-turn guidance that prompts your movements to properly position your probe for the view you want to capture.
Vscan Air™ SL with Caption AI™
Vscan Air SL with Caption Guidance™ software provides real-time guidance that shows you, step-by-step, how to maneuver the probe to capture diagnostic-quality standard echocardiographic views anytime, anywhere*.
At a glance
Prescriptive Guidance
Real-time, turn-by-turn prompts to help you properly position your probe
Quality Meter
The meter rises as the image improves and gets closer to diagnostic-quality
Save Best Clip
Tap save best clip to select the best available image loop for each view
AutoEF
Automatically calculates the LVEF from one or more views
Get more from your Vscan Air experience
Prescriptive Guidance
AutoCapture
For cases where you can reach the quality threshold, AutoCapture will automatically save your clip, hands-free. No need to tap store.
Save Best Clip
Tap save best clip to select the best available image loop for each view.
AutoEF
Automatically calculates the left ventricular ejection fraction from one or more of these three views: PLAX, AP2, and AP4. The calculation increases in accuracy as each view is acquired.
Caption AI Resources for Vscan Air SL
FAQs
- Caption AI is an Artificial Intelligence (AI) driven guidance software for conducting cardiac ultrasounds. Caption AI includes Caption Guidance™ and Caption Interpretation™ AutoEF software features:
• Caption Guidance software™, referenced as cardiac guidance on Vscan Air SL, is intended to assist medical professionals in the acquisition of cardiac ultrasound images.
• Caption Interpretation™ Ejection Fraction (“AutoEF”) software automatically calculates the left ventricular ejection fraction (LVEF) from one or any combination of these three views: PLAX, AP2, and AP4 to assist the clinician with their evaluation. The calculation increases in accuracy as each view is acquired. - There are 10 standard echo views available with guidance. These views can be customized with in any combination that best fit users’ workflow or indications-based needs. Enable/disable views and edit existing protocols with ease.
• Parasternal Long-Axis (PLAX)
• Parasternal Short-Axis Aortic Valve (PSAX-AV)
• Parasternal Short-Axis Mitral Valve (PSAX-MV)
• Parasternal Short-Axis Papillary Muscle (PSAX-PM)
• Apical 2-Chamber (AP2)
• Apical 3-Chamber (AP3)
• Apical 4-Chamber (AP4)
• Apical 5-Chamber (AP5)
• Subcostal 4-Chamber (SubC4)
• Subcostal Inferior Vena Cava (SC-IVC) - AutoEF is an AI interpretation of ejection fraction. Ejection fraction is a widely used measurement by cardiologists to assess heart function. At the end of every study, if one or a combination of sufficient quality PLAX, AP4, or AP2 views are captured, AutoEF will produce an ejection fraction calculation and inform you whether the calculated ejection fraction falls within the normal range, based on a mapping from ASE and ACEP guidelines.
- Color Doppler is accessible from within the Caption Guidance tool. However, Caption Guidance is not available to guide users to capture diagnostic-quality color Doppler images at this time. Images captured with color Doppler will be captured in free scan mode. Also note that because color Doppler images are captured in free scan, it is only to be done by those trained in cardiac ultrasound.
- Currently, Caption Guidance when used on Vscan Air SL is available on iOS and Android tablets larger than 7.3”.
References
* The device has been verified for limited use outside of professional healthcare facilities. Use is restricted to environmental properties described in the user manual.
